Mechatronics

GREENTECK GEARMOTORS

Powered by DECODER Electronics Industry

GREENTECK INDUSTRIAL

GREENTECK SEA

TECHNICAL FEATURES

2 sizes of geared motors: C30 + C40

• The 3 reduction ratios on the C30 are 1:20 ELECTROCARDANIC / 1:60 / 1:80
• The 3 reduction ratios on the C40 are 1:50 ELECTROCARDANIC / 1:60 / 1:80

A revolutionary electrocardanic reduction system with integrated mechanical clutch free of calibration and
wear over time, it is compatible with all of our control panels.

2 production lines:

• Greenteck INDUSTRIAL line characterised by the all-aluminium version
• Greenteck SEA line characterised by the all-black version where the gearbox body is produced with a
  special extremely resistant fibre formulated for use in saline environments.

Lubrication system with permanent grease completely free of maintenance or top-ups.

Customisation plaque with customer logo on the hub cap.

ELECTRICAL CHARACTERISTICS

Operating voltage: 230/400V.a.c. 50/60 Hz. THREE-PHASE

•  Power from 0.09KW to 1.3 KW
• Shaft output 1370/1650 RPM

Operating voltage 110 50/60 Hz. THREE-PHASE self-ventilated

• Powers from 0.09KW

Service: S1
Insulation Class: Class F / IP55
Energy Efficiency Class: IE1
